CNC Spring Machine

Your Professional CNC Spring Machine Supplier

Zhejiang Omnipoten Spring Machine Co., Ltd. is a leading spring machine manufacturer in China, specializing in CNC spring coiling machines, spring forming machines, spring grinding machines, spring seamless machines, spring temper furnaces, and other related equipment. The company has been awarded as the only national new technology enterprise in the spring machinery industry, and also the main member of China Spring Association.

Provide One-stop Solution

First of your perferred supplier of spring machinesfrom design to production.We adhere to provides global users.



Superb Process Technology

Global technologies for wire forming and spring making, aim to better products for customers with CNC Spring Coiling Machines.

Advanced Design Concept

WNJ equipment is designed with two things in mind: Value and Profit, Manufactured with high-value engineering.

Emerging Brand Development

WNJ is committed to building world world-class intelligent equipment brand in the spring machine industry.






Product Parameters



Model

GT20-10

GT25-10

GT28-12R

GT35-12R

Wire dia(mm)

Hard: 0.2-2.0mm
Soft: 0.4-2.8mm

Hard:0.2-2.5mm
Soft: 0.4-3.5mm

Hard:0.4-2.8 Soft:0.5-4.0

Hard:0.8-3.5 Soft:2.0-5.0

Max. wire feeding value
(mm)

10000.00mm

10000.00mm

10000

10000

Min. wire feeding value
(mm)

0.01mm

0.01mm

0.01

0.01

Max. wire feeding speed
(m/min)

120m/

120m/

120m/

80/

Max. wire feeding length



Unlimited

Unlimited

Axis number

10

10

12

12

Total output power of servo motors
(kw)

7.3KW

10.4KW

13.3KW

17.6KW

Program storage(plus)

3000

3000

3000

3000

Compressor air pressure(kg/cm)

5-6kg/cm²

5-6kg/cm²

5-6

5-6

Probe number

3

3

3

3

Machine Dimensions(L*W*H)(CM)

120*80*160
95*95*75

138*115*181
95*95*75

213*141*204 102*102*92

230*250*178 125*125*103

The feeding tray

100KG

200KG

200KG

300KG

Net weight(kg)

800kg

980kg

1600

2500



Model

GT40-12R

GT48-12R

GT50-12R

GT55-12R

Wire dia(mm)

Hard:1.2-4.0
Soft: 2.0-6.0

Hard:1.2-4.8
Soft: 3.0-8.0

Hard:1.2-5.0
Soft: 3.0-9.0

Hard: 2.0-5.5
Soft: 3.0-10.0

Max. wire feeding value
(mm)

10000

10000

10000

10000

Min. wire feeding value
(mm)

0.01

0.01

0.01

0.01

Max. wire feeding speed
(m/min)

80

80

80

80

Max. wire feeding length

Unlimited

Unlimited

Unlimited

Unlimited

Axis number

12

12

12

12

Total output power of servo motors
(kw)

21.8KW

23KW

26.7KW

29.5KW

Program storage(plus)

3000

3000

3000

3000

Compressor air pressure (kg/cm)

5-6

5-6

5-6

5-6

Probe number

3

3

3

3

Packing Size L*W*H(cm)

275*160*192
145*145*130

275*160*192
145*145*130

300*180*225
161*161*141

300*180*225
161*161*141

The feeding tray

400KG

400KG

500KG

500KG

Net weight(kg)

4100

5000

5500

6000



Model

GT60-12R

GT80-12R

GT100-12R

Wire dia(mm)

Hard: 2.0-6.0
Soft: 3.0-10.0

Hard: 3.0-8.0
Soft: 5.0-12.0

Hard: 4.0-10.0
Soft: 6.0-16.0

Copper bar(W*T*)

40*4 mm

50*5 mm

60*6mm

Max. wire feeding value (mm)

10000

10000

10000

Min. wire feeding value(mm)

0.01

0.01

0.01

Max. wire feeding speed(m/min)

80

70

60

Max. wire feeding length

Unlimited

Unlimited

Unlimited

Axis number

12

12

12

Total output power of servo motors
(kw)

38.4KW

55.0KW

88.5KW

Program storage (plus)

3000

3000

3000

Compressor air pressure (kg/cm)

5-6

5-6

5-6

Probe number

3

3

3

The feeding tray

500KG

1000KG

1000KG

Size(L*W*H)cm

350*210*220
161*161*141

350*210*220
205*205*150

350*220*230
205*205*150

Net weight(kg)

7500

9000

11000



Benefits of CNC Spring Machines

Improved Precision and Consistency

CNC spring coiling machines offer unmatched precision and consistency compared to manual coiling methods. Utilizing computer-controlled systems ensures that each spring is manufactured to exact specifications, effectively eliminating variations caused by human error. This level of precision is critical in industries that require highly accurate and consistent springs, such as aerospace, automotive, and medical.

productcate-800-450

Higher Production Efficiency

The automation provided by CNC machines significantly enhances production efficiency. These machines can produce large quantities of springs in a shorter amount of time, reducing lead times and increasing overall productivity. This enables manufacturers to meet tight deadlines, fulfill large-scale orders, and optimize their production capabilities.

productcate-800-450

Versatility and Flexibility

CNC spring coiling machines are capable of handling a wide variety of spring types, sizes, and configurations. With adjustable tooling and programmable settings, manufacturers can easily switch between different spring designs without the need for extensive retooling or manual adjustments. This versatility allows them to meet diverse customer requirements and tap into new market opportunities.

productcate-800-450

Cost Savings and Waste Reduction

By reducing the need for skilled manual labor, CNC spring machines help minimize labor costs. Automation also reduces the risk of human error and material waste, cutting down on costly rework. Additionally, the high production speed of CNC machines maximizes resource utilization, resulting in significant cost savings and improved operational efficiency.

productcate-730-411

Advanced Features and System Integration

CNC spring coiling machines come equipped with advanced features such as wire straightening, cutting, and bending mechanisms, ensuring a streamlined manufacturing process. Many machines offer real-time monitoring and diagnostics, allowing operators to quickly detect and resolve issues. Some models even include self-correction capabilities to compensate for wire variations. These features improve uptime, reduce downtime, and enhance overall performance.

productcate-730-411



Common Applications of CNC Spring Coiling Machines

1

Automotive Industry: CNC spring coiling machines are widely used in the automotive sector to manufacture springs for suspension systems, engines, transmissions, braking systems, and seat components.

2

Aerospace Industry: The aerospace industry relies on CNC spring coiling machines to produce high-precision springs for components requiring exceptional reliability and performance, such as landing gear, actuators, and control systems.

3

Electronics Industry: CNC spring coiling machines play a crucial role in producing springs for electronic devices, including connectors, switches, relays, and circuit boards.

4

Medical Industry: In the medical field, CNC spring coiling machines are used to manufacture springs for surgical instruments, implants, diagnostic devices, and various types of medical equipment.

5

Furniture Industry: These machines are used to produce springs for furniture applications such as upholstered chairs, sofas, mattresses, and other seating arrangements.

6

Consumer Goods: CNC spring coiling machines are employed in the production of various consumer products that incorporate springs, such as toys, home appliances, locks, and hardware.

7

Power and Energy Sector: CNC spring coiling machines are used in the energy and power generation industries to manufacture springs for turbines, generators, valves, and other power equipment.



Number of Axes

Primary Function

Key Features

Suitable Applications

2 Axes

Basic Coiling

Simple structure, easy operation, suitable for producing simple compression and tension springs.

Small-scale enterprises, customers with low production volume.

3-4 Axes

Complex Shapes

Can produce more complex spring shapes such as conical and disc springs.

Industries with specific requirements for spring shape, such as automotive and electronics.

5-7 Axes

High Precision

Offers higher positioning accuracy and repeatability, suitable for producing high-precision springs for medical devices, aerospace, etc.

Industries with high precision requirements for springs.

8-12 Axes

Advanced Functions

Enables more complex processing, such as multi-section and variable cross-section springs, suitable for producing various special-shaped springs.

High-end manufacturing, industries with extremely high requirements for spring performance.



Certificate

productcate-1-1
productcate-1-1
productcate-1-1



FAQ

Q: How is the quality of your machine?

A: We have been manufacturing spring coiling machine and wire bending machine for over 10 years. We have rich experience in machine production and assembly.

Q: What should we do if there is a problem with the machine?

A: Our machine comes with a one-year warranty from the date of B/L and we provide lifetime technical support.

Q: How can we learn to operate your machine?

A: 1).You can send people to our factory for training before machine delivering .
2). After the training, if your people still cannot operate the machine proficiently, we can provide online training.
3). Our sales team provide 24-hour pre-sales and after-sales service.

Q: What is your payment term?

A: The payment term is 40% deposit as PO confirmation, and 60% before the shipment. We also accept other payment term.

Q: Can you customize the machine for the customer?

A: Yes, we can. We also provide OEM for customer, if you need customize service, please contact us.

We're well-known as one of the leading CNC spring machine manufacturers and suppliers in China. Please rest assured to wholesale high quality CNC spring machine at competitive price from our factory. For custom service, contact us now.
